Model No.: ED5R-9
1. 6 years OEM & ODM Factory
2.ANSL/NEMA FL1-2009 Standard
3. CE, ROSH, FCC Approved
MAXTOCH ED5R-9 Stainless Steel 320 Lumens Cree LED Mini Torch Features: *LED Type: CREE XP-G R5 *Max output: 320LM *Beam: Micro Orange Peel Reflector for flawless beam
*Lens: Anti-shattering ultra clear lens, anti-scratching and anti-slip *Finish: HA ll *Waterproof: IPX7 *Modes: Min-Mid-Max *Battery: 1*CR123A or 16430 *Circuit efficiency: 93% Operation:
With the battery correctly inserted, screw the tail cap onto the body fully. Rotary Head Twisty Switch to change modes between Min-Mid-Max
*Remove the tail cap, insert the batteries with the positive ends toward the head of the light, replace the tail cap. Parameters:
|Max Output ( lm )||320||Runtime ( hr )||1|
|Distance ( m )||75||Battery||1 * 16340 Li-ion or CR123A|
|Weight ( g )||70||Size ( mm )||61*21.5|
*Mid output of 70 lumens for approximately 5 Hours
*Min output of 5 lumens for approximately 60 Hours Note:Stated brightness and runtime figures are based on tests using 1PC 16340 Li-ion battery under laboratory conditions. Variances in these figures will occur depending on batteries used and individual usage habits.
Contact us if you need more details on Mini Torch. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Led Mini Torch、Cree Led Mini Torch. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Maxtoch Flashlight
